Precision

Precise movements: over and over again

ULTRA.POS stands for outstanding precision, load capacity, efficiency and smooth running. Our positioning systems offer an excellent precision/price ratio and a significant increase in quality compared to conventional linear axes. They can be integrated easily, safely and efficiently. ULTRA.POS includes robust single-axis and multi-axis systems, such as cross tables, which are available in both manual/hand-operated and motorised versions. Our proven product standard saves you time and money, while you benefit from customisable solutions.

Application

Your requirements are the benchmark for our positioning systems

  • The standard does not fulfil your requirements? Then we will work with you to develop a customised solution.
  • Ready-to-install positioning units
  • Integration of electric drive possible
  • Individual solutions and serial products possible

    Function

    Features of positioning systems

    Positioning systems are used to precisely position an object. These systems enable movement along one or more axes, typically along the X, Y and Z axes, and are used in various areas of automation. The quality and performance of a positioning system are primarily judged by its positioning accuracy. This accuracy mainly depends on three factors:

    • Base: This includes material, structure and surface finish.
    • Type of guide: Precision rails, shaft guides or rollers.
    • Drive: Aspects such as zero backlash, smooth running and lubrication play a key role.

    For most industrial positioning tasks, a solution with an aluminium base plate, recirculating ball bearing guides and a ball screw drive is ideal. For lower positioning accuracy requirements, more cost-effective drive types such as trapezoidal screws or shaft guides such as ball bushings can be used. For very high positioning accuracy requirements, higher quality drives and guides are essential. Our promise to you is: We offer the optimum combination of base body, guide and drive for your individual application. Benefit from our many years of experience in the field of linear technology to optimise your application.

    Get free consulting now!

    Performance

    Performance range of the ULTRA.POS positioning systems

    Performance features
    Drive types

    Trapezoidal screw drives, ball screw drives or planetary roller screws

    Couplings, connections

    Adaptation to any servo and geared motors of all commercially available couplings. Matching motor adapter on request

    Equipment

    Integration of sensors, cable trailing and electrical connections

    Technical features

    Extremely high precision/price ratio, high running accuracies (<0.05mm/m), drive spindle in rolled (C7), whirled (C5) or ground (C3) precision

    Construction sizes

    Four standard sizes available

    Customised solutions

    Additional functions, drilling patterns, extra-long slides, ultra-compact multi-axis units (XY or XYZ version)

    Add-Ons

    Central lubrication, limit and reference switches, measuring systems, guideway cover via bellows, lifetime lubrication

    Materials

    Aluminium, anodised or continuos cast profile (Extruded profile)

    High process accuracy

    Extremely high precision/price ratio

    Advantages

    ULTRA.POS Positioning systems

    Positioning accuracy

    Achieve exceptional positioning accuracy, rigidity and load values with the right choice of guide, drive and a base body made of solid aluminium. You benefit from a compact design that is tailored to the available installation space and machine environment.

    Reliability

    Our solutions are tried and tested, reliable and durable. We pay attention to high quality, smooth running and accuracy throughout the entire process. Every positioning system is checked and tested before dispatch.

    Forward integration

    Take advantage of our partnership with leading brands in linear technology. You can select precision components from us regardless of the manufacturer. Efficiently implemented standards enable you to reduce costs in the areas of design, assembly and quality assurance.

    Customised: standard & special solutions

    You can choose from an extensive standard range and expertise for special solutions. In both cases, you have full control over the product: we create approval drawings and CAD data for you.

    Free enquiry

    FAQ

    Interesting facts about positioning systems

    What is the difference between a positioning unit and a linear axis?

    Linear axes are generally axes whose basic body is a continuous cast profile. Although they appear similar at first glance, they differ significantly in terms of precision and load values. Positioning units far exceed the performance characteristics of linear axes at comparable costs.

    Can positioning systems be supplied manually or with a motor?

    Positioning systems can be supplied with both. We supply the manual/ hand-operated version with a handwheel. For positioning systems with a motor, we either supply a suitable interface (coupling, flange, etc.) or integrate an electric motor/servo drive of your choice.

    What are typical applications for positioning units?

    Positioning units are used for all tasks in the automation industry. Every positioning process as part of a pick-and-place application, dispensing, etc. requires a guide and drive. Positioning systems are the ideal complement to simple drives in order to integrate these efficiently and smoothly.

      Workflow

      Your path to a customised solution

      1

      Needs
      assessment

      Let us know what you need – our experts will analyse your requirements to find the right solution for you.

      2

      Proposed solution
      & offer

      Customised solutions quickly require a target price and a delivery time. On the basis of an initial discussion, we provide you with solution proposals for your decision.

      3

      Development
      & implementation

      Our team develops a customised solution that is precisely tailored to your specific needs. We offer both from a single source.

      4

      Commissioning
      & support

      We are also there for you personally during commissioning. With our after-sales service, we support you from implementation to the last shift of the machine.
